If drops aren't your thing but you want the freedom of gravel riding, Search A Flat Bar is ready for your next adventure!
Search A Flat Bar features new-school gravel geo fit for a fast, lively, confident ride on any terrain. With a taller headtube, slacker head angle, and longer reach, it’s more stable on rough terrain and ready to tackle steeper grades with ease.
The updated, longer fork adds stability and new-school geometry is compatible with suspension forks if you want to add some extra cushion. The frame is UDH compatible and supports fitments for all the latest wide range 1x drivetrain technologies.
Fully guided cable routing and a fully threaded BSA bottom bracket makes maintenance a breeze.
| Weight: | 12.6 kg (27.8 lbs) |
|---|---|
| Frame: | Search Butted Aluminum w/Smooth Welds |
| Fork: | Search Carbon, 51mm Offset, 12x100mm TA |
| Shock: | N/A |
| Front Shifter: | N/A |
| Front Derailleur: | N/A |
| Rear Shifter: | Shimano CUES 9spd SL-U4000 Rapid Fire |
| Rear Derailleur: | Shimano CUES RD-U4000 |
| Crankset: | Prowheel, 38T, ST, 170mm (S1,S2,S3,S4) - 172.5mm (S5) |
| Pedals: | N/A |
| Bottom Bracket: | Shimano Cartridge Bearing, 68mm BSA |
| Cassette: | Shimano CS-LG300, 11-46T, 9sp |
| Chain: | KMC Z9 |
| Front Brake: | Tektro HD-R280 Hydraulic |
| Front Brake Rotor: | Tektro 6-Bolt - 160mm |
| Rear Brake: | Tektro HD-R280 Hydraulic |
| Rear Brake Rotor: | Tektro 6-Bolt - 160mm |
| Brake Levers: | Tektro HD-R280 Hydraulic Hydro 3-Finger Levers w/ Reach Adjust |
| Front Hub: | Formula, 28H, 6-Bolt |
| Front Hub Skewer: | 12x100mm Thru Axle |
| Rear Hub: | Formula, HG, 28h, 6-Bolt |
| Rear Hub Skewer: | 12x142mm Thru Axle |
| Rims: | WTB ST i25 2.0, 28h, 25mm ID |
| Front Tire: | Schwalbe G-One Comp, K-Guard Recyclable, 700x40c |
| Rear Tire: | Schwalbe G-One Comp, K-Guard Recyclable, 700x40c |
| Handlebar: | Norco Alloy, 620mm (S1,S2) 640mm (S3,S4,S5), 15mm rise |
| Grips/ Bar Tape: | Norco Lock On, 130 length |
| Stem: | Norco Alloy 70mm Length, 31.8mm Clamp |
| Headset: | FSA Integrated Sealed Bearings No. 42 ; Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
| Saddle: | Selle Royale SRX Gravel, 148mm |
| Seatpost: | Aluminum 27.2mm |
| Extras: |
