| Weight: |
TBD |
| Frame: |
500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden fender mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12mm chamfere |
| Fork: |
Trek Checkpoint, full carbon, tapered steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle |
| Shock: |
N/A |
| Front Shifter: |
SRAM Rival AXS E1 13spd |
| Front Derailleur: |
N/A |
| Rear Shifter: |
SRAM Rival AXS E1 13spd |
| Rear Derailleur: |
SRAM Rival XPLR AXS, 46T max cog |
| Crankset: |
SRAM Rival E1 XPLR, 40T, DUB Wide, 160mm length, Medium: 165mm, Large: 170mm |
| Pedals: |
N/A |
| Bottom Bracket: |
SRAM DUB Wide, T47 threaded, internal bearing |
| Cassette: |
Sram Rival XPLR XG-1351, 10-46, 13 speed |
| Chain: |
SRAM Rival E1, 12/13 speed |
| Front Brake: |
Sram Rival Hydraulic |
| Front Brake Rotor: |
SRAM Paceline, rounded, centerlock, 160mm |
| Rear Brake: |
Sram Rival Hydraulic |
| Rear Brake Rotor: |
SRAM Paceline, rounded, centerlock, 160mm |
| Brake Levers: |
SRAM Rival Hydraulic |
| Front Hub: |
100mm Center lock disc hubs with 12mm thru-axle front and rear, Bontrager Rapid Drive 108 road hub |
| Front Hub Skewer: |
Bontrager Switch Lever Pro Front Thru Axle 12x119.5mm |
| Rear Hub: |
SRAM XDR freehub 142mm, Center lock disc hubs with Bontrager Rapid Drive 108 road hub |
| Rear Hub Skewer: |
Bontrager Switch Lever Pro Rear Thru Axle 12x166mm |
| Rims: |
35mm depth OCLV Carbon rim (32mm outer, 25mm inner width) 14/16/14 bladed spokes, alloy locking nipples |
| Front Tire: |
Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42mm |
| Rear Tire: |
Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42mm |
| Handlebar: |
Bontrager Pro Gravel, 40cm width, Medium: 42mm, Large: 44mm |
| Grips/ Bar Tape: |
Trek Gel Cork Handlebar Tape Set, Black, 3mm |
| Stem: |
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length, Large: 90mm |
| Headset: |
Carbon Steerer |
| Saddle: |
Verse Short Comp, steel rails, 145mm width |
| Seatpost: |
Bontrager carbon, 27.2mm, 8mm offset, 330mm length |
| Extras: |
|
