| Weight: |
56 - 8.89 kg / 19.6 lbs (with TLR sealant, no tubes) |
| Frame: |
500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle |
| Fork: |
Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
| Shock: |
N/A |
| Front Shifter: |
Shimano 105 R7170 Di2, 12 speed |
| Front Derailleur: |
Shimano 105 R7150 Di2, braze-on, down swing |
| Rear Shifter: |
Shimano 105 R7170 Di2, 12 speed |
| Rear Derailleur: |
Shimano 105 R7150 Di2, 36T max cog |
| Crankset: |
Shimano 105 R7100, 50/34, Size 47, 50 - 165mm, Size 52, 54, 56 - 170mm, Size 58, 60, 62 - 172.5 |
| Pedals: |
N/A |
| Bottom Bracket: |
Praxis, T47 threaded, internal bearing |
| Cassette: |
Shimano 105 7101, 11-34, 12 speed |
| Chain: |
Shimano SLX M7100, 12 speed |
| Front Brake: |
Shimano 105 hydraulic disc, flat mount |
| Front Brake Rotor: |
Shimano CL700, centerlock, 160mm |
| Rear Brake: |
Shimano 105 hydraulic disc, flat mount |
| Rear Brake Rotor: |
Shimano CL700, centerlock, 160mm |
| Brake Levers: |
Shimano 105 R7170 Di2, 12 speed |
| Front Hub: |
100mm centerlock |
| Front Hub Skewer: |
12x100mm thru axle |
| Rear Hub: |
Bontrager Rapid Drive 108 hub |
| Rear Hub Skewer: |
12x142mm thru axle |
| Rims: |
Bontrager Aeolus Elite 35 TLR Disc Road Wheel |
| Front Tire: |
Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm |
| Rear Tire: |
Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32mm |
| Handlebar: |
Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, Size 47 - 36-40cm, Size 50,52 - 38-42cm, Size 54, 56, 58 - 40-44cm, Size 60, 62 - 42-46cm |
| Grips/ Bar Tape: |
Trek EcoTack |
| Stem: |
Trek RCS Pro, -7 degree, Size 47 - 70mm, Size 50 - 80mm, Size 52, 54, 90mm, Size 56, 58 - 100mm, Size 60, 62 - 110mm |
| Headset: |
|
| Saddle: |
Verse Short Comp, steel rails, 145mm width |
| Seatpost: |
KVF aero carbon seatpost, 20mm offset, Size 47, 50, 52, 54, 56 - 280mm, Size 58, 60, 62 - 320mm |
| Extras: |
|
